Antena Nanostation M5 Airmax 5.8Ghz Mimo Antena 16Dbi

Modelo: Nsm5 Homologado Anatel : Nh: 2984-10-5966 Apresentando Um Desempenho Da Antena Painel E Dual-Polaridade, A Nanostation M É Ideal Para Aplicações Ponto-A-Multiponto (Ptmp) Que Exigem Dispositivos Cpe De Alta Performance Com Um Fator De Forma Elegante. Caracteristicas Shock And Vibration Etsi300-019-1.4 Frequency Range 4.9-5.9 Ghz Gain 14.6-16.1dbi . Polarization Cross-Pol Isolation Dual Linear Power Method Passive Power Over Ethernet (Pairs 4,5+. 7,8 Return) Operating Temperature -30c To +80c Operating Humidity 5 To 95 Condensing Mounting Kit Pole Mounting Kit Included Max Power Consumption 8 Watts Power Supply 24v, 0.5a Surge Portection Integrated Poe Adapter Included Enclosure Size 29.4 Cm X 8 Cm X 3cm Weight 0.4kg Enclosure Characteristics Outdoor Uv Stabalized Plastic Physical / Electrical / Environmental 22db Minimum Max Vswr 1.6:1 H-Pol Beamwidth V-Pol Beamwidth Elevation Beamwidth 43 Deg. 41 Deg. 15 Deg. 5ghz Tx Power Specifications 5ghz Rx Specifications 11a 11a 5ghz 11n 5ghz 11n Wireless Approvals Fcc Part 15.247, Ic Rs210, Ce Rohs Compliance Yes Vswr H-Pol Azimuth H-Pol Elevation V-Pol Azimuth V-Pol Elevation Integrated 2x2 Mimo Antenna Regulatory / Compliance Information Operating Frequency 5745mhz-5825mhz Networking Interface 2 X 10/100 Base-Tx (Cat. 5, Rj-45) Ethernet Interface Processor
